S4 Intel CPU Cooler
S4 CPU cooler is designed based on intel platform, this heatsink uses down pressure air duct design, which can cover both CPU main body and surrounding electronic components thermal issues. The cooling fan is placed on the top to realize the downward push air flow design and improve the good...
Product Introduction
One of the most critical components that people often overlook when building high-end computers is the CPU cooler. The processor is the core part of the machine and generates a lot of heat when running demanding programs or games. Overheating can cause system crashes, performance degradation, and even damage the chips, shortening their working life. So build a effective CPU cooler is essential to keep your CPU running smoothly and extend its lifespan.
The S4 Intel CPU Cooler was designed for Intel processors. Intel provides different thermal design power (TDP) ratings for its processors based on factors such as core count, base frequency, cache size, and more. A good cooler should match the TDP of the CPU to ensure it can handle the heat generated by the processor without causing damage. The S4 Intel CPU Cooler is ideal for high-end Intel processors, providing enough cooling performance to prevent overheating and keep the CPU running at its maximum potential.
Also this kind of Intel CPU Cooler has a compact design that fits easily in even the tiniest of cases. Some CPU coolers can be bulky, take up a lot of space, and interfere with other components like RAM or graphics cards. But the S4 Intel CPU Cooler has a slim profile, allowing it to fit in tight spaces without obstructing any other components. Plus, the cooler features a tool-less mounting system that anyone can easily install, even without any technical expertise.
Most importantly the S4 Intel CPU cooler runs quietly, making it perfect for those who want to silence their computer. When running programs or games, the CPU fan makes a lot of noise, which can be distracting and annoying. The S4 Intel CPU cooler produces low noise levels thanks to its efficient, Low Noise Bearing (LNB) fan. LNB bearing technology optimizes the performance of the fan, reducing friction and noise while increasing cooling efficiency.
This CPU cooler is an affordable yet powerful option for anyone looking for a high-quality cooler. Some CPU coolers can cost hundreds of dollars, making them an expensive investment. On the other hand, compared to other high-end coolers, the S4 Intel CPU cooler is cost-effective.
Summarize the benefits of S4 Intel CPU cooler as below:
1. Compatible with Intel processors.
2. Compact design and easy installation.
3. Quiet operation.
4. Affordable price.
Product Specifications:
| Heatsink Size(MM) | 1039*92*23 | Fan Size(MM) | 92*92*15 |
| Total Weight(g) | 233g | Rated Voltage | 12V |
| Operation Voltage | 10.8-13.2VDC | Start Voltage | 7VDC |
| Rated Current | 0.26±10%A | Input Power | 3.12W |
| Fan Speed | 1200-3300±10%RPM | PIN | 4 pins |
| Fan Wire | 200mm | Fan Life | 40000+hours |
| Air Volume | 48.9CFM | Fan Noise | 15-33db(A) |
| Bearing | Hydraulic Bearing | CPU | INTEL LGA115X/1200 |
Design Details:
1. 4pcs copper heatpipe are buried in aluminum base by rooling and soldering base to get high flatness, the directly contact with CPU , this allows the heat transfer to heatsink module quickly.

2. A fan supporting intelligent temperature control function is configured, which not only has sufficient air volume, but also ensures silence.

Factory and workshop

Certificates



Sinda Thermal is a leading thermal manufacturer in China, our factory was founded in 2014, and located in Dongguan city, China, we are offering varieties of heatsinks and other precious metal parts. Our plant possesses 30 sets advanced and high precious CNC machines and stamping machines, also we have many testing and experiment instruments and professional engineering team, so our company can manufacture and provide high quality products with high precision and excellent thermal performance. Sinda Thermal is commited to a range of heat sinks which are widely used in new power supply, New energy vehicles, Telecommunications, Servers, IGBT, and Madical. All the products accord with Rohs/Reach standard, and the factory is qualified by ISO9001 and ISO14001. Our company has been a partner with many customers for good quality, excellent service and competitive price. Sinda Thermal is a great heat sink manufacturer for the global customers .
FAQ
1. Q: Are you a trading company or manufacturer?
A: We are a leading heat sink manufacturer, our factory has been founded over 8 years, we are professional and experienced.
2. Q: Can you provide OEM/ODM service?
A: Yes, OEM/ODM are available.
3. Q: Do you have MOQ limit?
A: No, we don't set up MOQ, prototype samples are available.
4. Q: What's the lead time of the production?
A: For prototype samples, the lead time is 1-2 weeks, for mass production, the lead time is 4-6 weeks.
5. Q: Can I visit your factory?
A: Yes, Welcome to Sinda Thermal.
